96KW Photovoltaic Storage System Cabinet

Model no: 96KW Photovoltaic Storage System Cabinet

Features:

- Battery Type: LiFePO₄ (LFP) with 6000 cycles @ 80% DoD.
- Rated Energy: 96 kWh .
- Wall-mounted, compact, and fire-resistant design.
- Smart protection: over/under voltage, current, temperature, discharge, and short-circuit.
- Integrated BMS with CAN and RS485 communication.
- Monitoring Bluetooth (PACE EX) through a mobile device’s app.
- Operating temperature: -20°C to 55°C (discharge).
- Extensible — connect up to 15 batteries in parallel.
- Warranty: 5 Years

96KW Photovoltaic Storage System Cabinet is engineered for high safety and reliable energy storage using advanced LiFePO₄ technology. With a 6000-cycle lifespan and a fireproof, wall-mounted design, it offers compact efficiency for both home and commercial use. Equipped with a smart BMS supporting CAN and RS485 communication, it ensures stable operation and easy system integration. The built-in Bluetooth (PACE EX) feature enables real-time monitoring through mobile devices. Tiger Pro provides complete protection against voltage, current, temperature, and short-circuit issues, making it a durable and secure choice for modern energy storage.

Technical Specifications

Product Model	96KW-ESS-SYSTEM
Battery Type	LiFePO₄ / LFP
Rated Capacity (Energy)	96 kWh
Voltage Range	240V - 351.6V
Rated Power	30 - 60 KW
Maximum Efficiency	98.4% - 99%
Output Voltage	3/N/PE, 230V/400Vac
Energy Management System	BMS / EMS
Communication Interface	RS485, CAN, Ethernet, 4G/5G
Temperature Control	Air Cooling
Operating Temperature	-30°C to +50°C
Dimensions (L×W×H)	1270 × 1050 × 2050 mm
Weight	Approx. 850 kg
Mounting	Floor-standing Cabinet
