Tiger Energy Pro

261kWh Integrated Energy Storage Cabinet

Model no: 261kWh Integrated Energy Storage Cabinet

Features:

    • Battery Type: LiFePO₄ (LFP) with 6000 cycles @ 80% DoD.
    • Rated Energy: 261 kWh .
    • Wall-mounted, compact, and fire-resistant design.
    • Smart protection: over/under voltage, current, temperature, discharge, and short-circuit.
    • Integrated BMS with CAN and RS485 communication.
    • Monitoring Bluetooth (PACE EX) through a mobile device’s app.
    • Operating temperature: -20°C to 55°C (discharge).
    • Extensible — connect up to 15 batteries in parallel.
    • Warranty: 5 Years

261kWh Integrated Energy Storage Cabinet is engineered for high safety and reliable energy storage using advanced LiFePO₄ technology. With a 6000-cycle lifespan and a fireproof, wall-mounted design, it offers compact efficiency for both home and commercial use. Equipped with a smart BMS supporting CAN and RS485 communication, it ensures stable operation and easy system integration. The built-in Bluetooth (PACE EX) feature enables real-time monitoring through mobile devices. Tiger Pro provides complete protection against voltage, current, temperature, and short-circuit issues, making it a durable and secure choice for modern energy storage.

fNnBhUu9G scaled
Call Now
WhatsApp

Technical Specifications

Product Model Energy Storage System
Nominal Energy261 kWh
Nominal Voltage832 V
Voltage RangeDC 728 V - 936 V
Maximum Current179.4 A
Rated Power125 kW
Maximum Output Power137.5 kVA
Rated AC Output Current180.4 A
Maximum AC Output Current198.4 A
Rated Mains Voltage400 V
Allowed Grid Frequency50 Hz ± 2.5 Hz
Dimensions (L×W×H)1300 × 990 × 2500 mm
WeightApprox. 2.7 t
Maximum Permitted Altitude≤ 3000 m / < 4000 m
System Cycle Life≥ 8000 cycles
IP RatingIP54
